Thermal Inkjet Printers

Dotjet thermal inkjet printers offer an impressive combination of functionality and simplicity in one, compact design, where high quality print is essential and ease of use is a primary consideration. Three types of TIJ printers from the DJ1 with very simple structure but very robust to the DJ45x which can satisfy with most of inkjet coding need, further the DJ45plus is a versatile printer excellently perform in advanced inkjet applications. Dotjet’s TIJ printers provide an ideal solution for a wide range of coding and marking applications, it is worth your exploration.

DJ45plus

  • Functional and versatile software ability
  • Multiple interfaces capable of printing external data
  • Printing via internet connection



The DJ45plus is an advanced version of the DJ45x, with full functions of the DJ45x. Based on the DJ45x, it further expands the capability of data printing and printer control from an external device, such as data printing received through communication interfaces like RS232, USB, and Ethernet. Printing control by protocol commands. Receive the print file, data, and image remotely from a central PC. Printer screen can be monitored and operated through wifi, MySQL database printing..etc., it performs versatile functions to apply in a wide range of coding and marking applications.

Full of DJ45plus inkjet printing functions
Owning versatile inkjet printing functions beyond your expectation, WYSIWYG user-friendly software provides a way can straightforward to create a print template and quickly set up parameters.

dj45x 02







Multiple Communication Interfaces

The software of DJ45plus was designed to support multiple communication interfaces including TCP/IP, RS232, USB and Wifi(By Router), emphasize the extending of coding and marking capability. Through the communication interfaces, let the DJ45plus becomes a versatile TIJ printer performing various applications in diverse industry. Some applications look complicated, Dotjet work team will give you fully support and simplify your customers particular printing request and assist you easily execute wide range of applications beyond basic printing.



usb







Remote

Control

Monitoring and managing Dotjet’s inkjet printers remotely has become very easy, it secures printing job is running on a production line error-free, conveniently supervisor remotely manages and check up on all inkjet printers running status installed at different locations in your network’s range. The Dotjet’s inkjet printers come with wireless and wifi connection capabilities, plus Dotjet owns develop printer remote management software and teamwork support, it worth you experience the advanced function.

 dj4504







Automating Database Printing

Use a database documenter to print the design template of database objects. The database can be saved in advance in the Dotjet’s printer memory via USB driver or convey single data via Ethernet from a PC. Furthermore, fetching data from a MySql database which allow Dotjet’s inkjet printers print respective database objects of a common MySQL database. The function can expand to various inkjet application, contact Dotjet’s team work to learn more.




dj45 3







Printing

Protocol

Dotjet’s inkjet printers provide multiple printing protocols given the communication method for an automatic centra system, print servers or a host computer. The protocols allow an external system to submit one or more print jobs to Dotjet’s inkjet printers and perform tasks such as querying the status of a printer, obtaining the status of print jobs, or canceling individual print jobs. The feature allows for the utmost flexibility, future expandability and helps manufacturers comply with the track-trace regulations of various industries.



 dj4504







Printing Data Collection

All kinds of printing data from Dotjet’s inkjet printers can be collected in a private server, this includes metadata about all the printing message that you print, including timestamps, printer ID, printing count, text and numbers in the print message, and the ink consumption status.

Dotjet developed a Data analytics software tools enable to analyze vast stores of data for great advantage on production line management. The Data analytics software can mine data that tracks a production activity – from current sales to historic inventory – and process it based on data scientists’ queries.



dj4505







Bulk Ink Supply



Efficiently to save time and money in mass products coding requirement
Water Bulk Ink – Adopt a very simple structure to extend ink supply with a 370ml bulk ink, disposable ink box, easy to install.



Solvent Bulk Ink - 400ml ink capacity meet the need of high-volume print application, low per copy, and minimal user intervention required.

dj4507







dj45 6



Specifications

Technology

 HpTIJ2.5

Power requirement

 AC110-220V, 50/60HZ

Display

 7” Color LCD with LED backlight

Operating temperature

 5℃ to 45℃ (41°F - 112°F)

Controller operating system

 Linux

Message storage

 Up to 999 messages

Print head controlled ability

 Two hp TIJ2.5 print heads

Print line

 Multuple depand on character size

Print height

 Selectable font size from 1mm to 12.7mm

Print speed

 60m/min (Water ink)
 90m/min (Solvent ink)

Max. print length

 1 meter

Print resolution

 Max. 600dpi x 600dpi / Regular 300dpi x 300dpi

Ink throw distance

 Recommended 6mm

LED Indicators

 Ink low, print on/off

Print Capability

 Alphanumeric, logos, date/time, shift code, serial number, lot/box number,
 GS1 barcodes/2D code, database and 27 languages characters print, External data

User interface

 WYSIWYG. Multiple-language available (some may need translation)

External data  interface

 RS232, USB, Ethernet, TCP/IP

Database print format

 CSV

Particular features

 MySQL database, print data collection, protocol control,
 image in database, multiple printer remote control by DotW_CM software

Print head data line

 Standard 75cm, maximum 200cm

Weight

 Controller 820g (Excluding bracket)
 Print head 380g (Excluding cartridge and bracket)

Dimension (L/W/H)

 Controller  205x140x68 (mm) / 8.1x5.5x2.7 (inches)
 Print head 130x115x94 (mm) / 5.1x4.5x3.7 (inches)

Optional

 Encoder, bulk ink supply, backstage analysis/manage software

Multiple I/O Functions Box

To manage diverse applications need the printer control by external machine interface, the functional box with 8 connectors flexibly for defining to Input or Output in parallel or serial signal.



more01





Photocell/Encoder Signal HUB

Splitting photocell and encoder signal into multiple outputs synchronize all printers start printing in one signal source.



more02





qrcode

Mini Router

300Mbps wireless data rates provides the DJ45plus to performs wireless connection with external device or system. Easy installation in minutes.





Protocol Button

Allowing the printing protocol embed in the button to implement remote control by the buttons.



  • Start print
  • Stop print
  • Reset print count
  • Open a file count
    ...Multiplicity as your define

qrcode
